ASR101
1U Full-size Rackmount Chassis

Revolsys 1U Full-Size Server Grade

Rackmount Chassis With 2 x 3.5" HDD Hotswapable Bays & redundant

power supply

Features & Benefits

● Supports ATX/CEB, EATX/EEB MB

● Up to 7 x 4028mm or 4056mm fans
● HDD tray with key lock optional

● Single or redundant PSU optional
● 2 x 3.5” HS SAS/SATA2 HDD bays
● 1 x 5.25” drive bay

Specifications

Material

Form Factor

Power Supply

Drive Capacity

Cooling Fan

Front I/O Ports

LED Indicators

Buttons

Expansion Slots

Dimensions (DxWxH)

Heavy Duty Metal

1U Chassis, Supports ATX/CEB, EATX/EEB MB

Single or Redundant 1U PSU Optional

2 x 3.5" Hot Swappable SAS/SATA2 HDD
1 x 5.25" Drive Bay

4028mm or 4056 Fan, up to 7 pcs

2 x USB

Power on, HDD, LAN x 2

Power, Reset

1 x Full Height Slot via Riser Card

670mm x 430mm x 44mm
