ASR402
4U Rackmount Chassis

Revolsys 4U Server Grade Rackmount

Chassis Designed To Supports Upto

10 Full Expansion Slots

Features & Benefits

● Supports ATX/CEB MB

● 1 x 120mm fan, 2 x 60mm fans
● Supports up to 10 PCI Slots with ATX MB integrating 5 PCI slots

● Single PSU st the front side
● Optional drive bays

Specifications

Material

Form Factor

Power Supply

Drive Capacity

Cooling Fan

Front I/O Ports

LED Indicators

Buttons

Expansion Slots

Dimensions (DxWxH)

Heavy Duty Metal

4U Chassis, Supports ATX/CEB MB

500W PS2 PSU

Option 1: 3 x 5.25" drive bay, 1 x 3.5" external drive bay
1 x 3.5" Internal drive bay
Option 2: 1 x 5.25" drive bay, 1 x 3.5" external drive bay
4 x 3.5" internal drive bay

1 x 120mm Fan ; 2 x 60mm Fans

2 x USB

Power on, HDD

Power, Reset

Support One PCI Expansion Board with One PCIE to PCI32 Bridge Chip
Support PCI Board with 5 Full Length PCI32 Slots

539mm x 425mm x 178mm
